Scaffolding

Galvanized Scaffold Tubes 4mm

KwikUP Scaffoling supplies Scaffold Tubes which comly with Australian standards AS1576.3 & AS1576.1 App A clause A5 – steel tubes Tubes come in sizes from 0.3 m to 6.3 m and in packs / bundles of 61 pcs KwikUP supplies various types of forged fittings along with scaffolding tubes Scaffold tubes end can be painted in any colour of your choice

Size	Weight	Item Description	Select All
0.3	1.27	48.30 OD X 4 mm Thick	✓
0.6	2.54	48.30 OD X 4 mm Thick	✓
0.9	3.81	48.30 OD X 4 mm Thick	✓
1.2	5.08	48.30 OD X 4 mm Thick	✓
1.5	6.36	48.30 OD X 4 mm Thick	✓
1.8	7.63	48.30 OD X 4 mm Thick	✓
2.1	8.9	48.30 OD X 4 mm Thick	✓
2.4	10.17	48.30 OD X 4 mm Thick	✓
2.7	11.22	48.30 OD X 4 mm Thick	✓
3	12.71	48.30 OD X 4 mm Thick	✓
3.3	13.98	48.30 OD X 4 mm Thick	✓
3.6	15.25	48.30 OD X 4 mm Thick	✓
3.9	16.52	48.30 OD X 4 mm Thick	✓
4.2	17.8	48.30 OD X 4 mm Thick	✓
4.5	19.07	48.30 OD X 4 mm Thick	✓
4.8	20.34	48.30 OD X 4 mm Thick	✓
5.1	21.61	48.30 OD X 4 mm Thick	✓
5.4	22.88	48.30 OD X 4 mm Thick	✓
5.7	24.15	48.30 OD X 4 mm Thick	✓
6	25.42	48.30 OD X 4 mm Thick	✓
6.3	26.69	48.30 OD X 4 mm Thick	✓
6.5	27.54	48.30 OD X 4 mm Thick	✓

Add selected to cart ✓

Add to Enquiry

Double Coupler

A strong drop forged coupler that connects two Scaffold tubes of 48.3 OD providing strength under load bearing situations joining tubes at 90 degree angles.

Size	Weight	Item Description	Quantity	Select All
48.3 mm	1.1	No Description		✓
default variation	1.1	No Description		✓

Add selected to cart ✓

Add to Enquiry

Swivel Coupler

A strong drop forged coupler like the double coupler but more flexible as it connects scaffold tubes at any angle required.

Size	Weight	Item Description	Quantity	Select All
48.3 mm	1.1	No Description		✓

Add selected to cart ✓

Add to Enquiry

Swivel Coupler 60mm X 48 mm

A strong drop forged coupler like the double coupler but more flexible as it connects scaffold tubes at any angle required.

Size	Weight	Item Description	Quantity	Select All
60 mm X 48.3 mm	1.1	No Description		✓

Add selected to cart ✓

Add to Enquiry

Beam Clamp / Girder coupler

A strong forged steel fitting providing quick and secure fixing to beams Always to be used in pairs

Size	Weight	Item Description	Quantity	Select All
48.3 mm	1.5	No Description		✓
default variation	1.5	No Description		✓

Add selected to cart ✓

Add to Enquiry

Swivel Beam Clamp / Girder coupler

A strong grip like the Beam Clamp but has a swivel capability to connect a beam at any angle required.

Size	Weight	Item Description	Quantity	Select All
48.3 mm	2.9	No Description		✓
default variation	2.9	No Description		✓

Add selected to cart ✓

Add to Enquiry

Putlog single coupler

Connects putlog or transom tubes to ledger tubes for the support of scaffold boards. The one-piece body has been carefully designed and press-formed to provide the maximum resistance.

Size	Weight	Item Description	Quantity	Select All
48.3 mm	0.77	No Description		✓
default variation	0.77	No Description		✓

Add selected to cart ✓

Add to Enquiry

Double Putlog Coupler

Makes connection of putlogs and transoms to standard scaffold tube while allowing scaffold boards to be laid on top of the tube.

Size	Weight	Item Description	Quantity	Select All
0.3 M	1.1	No Description		✓
default variation	1.1	No Description		✓

Add selected to cart ✓

Add to Enquiry

External Joint Pin

A one piece heavy duty coupler for rapid connection featuring a central baffle plate for correct tube positioning and unique individual one side unlocking safety feature.
