Galvanized Scaffold Tubes 4mm
KwikUP Scaffoling supplies Scaffold Tubes which comly with Australian standards AS1576.3 & AS1576.1 App A clause A5 – steel tubes Tubes come in sizes from 0.3 m to 6.3 m and in packs / bundles of 61 pcs KwikUP supplies various types of forged fittings along with scaffolding tubes Scaffold tubes end can be painted in any colour of your choice
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 0.3 | 1.27 | 48.30 OD X 4 mm Thick | |||
| 0.6 | 2.54 | 48.30 OD X 4 mm Thick | |||
| 0.9 | 3.81 | 48.30 OD X 4 mm Thick | |||
| 1.2 | 5.08 | 48.30 OD X 4 mm Thick | |||
| 1.5 | 6.36 | 48.30 OD X 4 mm Thick | |||
| 1.8 | 7.63 | 48.30 OD X 4 mm Thick | |||
| 2.1 | 8.9 | 48.30 OD X 4 mm Thick | |||
| 2.4 | 10.17 | 48.30 OD X 4 mm Thick | |||
| 2.7 | 11.22 | 48.30 OD X 4 mm Thick | |||
| 3 | 12.71 | 48.30 OD X 4 mm Thick | |||
| 3.3 | 13.98 | 48.30 OD X 4 mm Thick | |||
| 3.6 | 15.25 | 48.30 OD X 4 mm Thick | |||
| 3.9 | 16.52 | 48.30 OD X 4 mm Thick | |||
| 4.2 | 17.8 | 48.30 OD X 4 mm Thick | |||
| 4.5 | 19.07 | 48.30 OD X 4 mm Thick | |||
| 4.8 | 20.34 | 48.30 OD X 4 mm Thick | |||
| 5.1 | 21.61 | 48.30 OD X 4 mm Thick | |||
| 5.4 | 22.88 | 48.30 OD X 4 mm Thick | |||
| 5.7 | 24.15 | 48.30 OD X 4 mm Thick | |||
| 6 | 25.42 | 48.30 OD X 4 mm Thick | |||
| 6.3 | 26.69 | 48.30 OD X 4 mm Thick | |||
| 6.5 | 27.54 | 48.30 OD X 4 mm Thick |
Double Coupler
A strong drop forged coupler that connects two Scaffold tubes of 48.3 OD providing strength under load bearing situations joining tubes at 90 degree angles.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 48.3 mm | 1.1 | No Description | |||
| default variation | 1.1 | No Description |
Swivel Coupler
A strong drop forged coupler like the double coupler but more flexible as it connects scaffold tubes at any angle required.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 48.3 mm | 1.1 | No Description |
Swivel Coupler 60mm X 48 mm
A strong drop forged coupler like the double coupler but more flexible as it connects scaffold tubes at any angle required.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 60 mm X 48.3 mm | 1.1 | No Description |
Beam Clamp / Girder coupler
A strong forged steel fitting providing quick and secure fixing to beams Always to be used in pairs
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 48.3 mm | 1.5 | No Description | |||
| default variation | 1.5 | No Description |
Swivel Beam Clamp / Girder coupler
A strong grip like the Beam Clamp but has a swivel capability to connect a beam at any angle required.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 48.3 mm | 2.9 | No Description | |||
| default variation | 2.9 | No Description |
Putlog single coupler
Connects putlog or transom tubes to ledger tubes for the support of scaffold boards. The one-piece body has been carefully designed and press-formed to provide the maximum resistance.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 48.3 mm | 0.77 | No Description | |||
| default variation | 0.77 | No Description |
Double Putlog Coupler
Makes connection of putlogs and transoms to standard scaffold tube while allowing scaffold boards to be laid on top of the tube.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 0.3 M | 1.1 | No Description | |||
| default variation | 1.1 | No Description |
External Joint Pin
A one piece heavy duty coupler for rapid connection featuring a central baffle plate for correct tube positioning and unique individual one side unlocking safety feature.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 0.3 M | 1.5 | No Description | |||
| default variation | 1.5 | No Description |
Internal Joint Pin
designed for rapid ‘end to end’ connection of standard scaffolding tubes
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 0.3 M | 1.5 | No Description | |||
| default variation | 1.5 | No Description |
Board Holding Clip
We offer qualitative board retaining couplers , which is widely demanded for immediate and secured locking of the boards in the proper position.
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 0.3 M | 0.65 | No Description | |||
| default variation | 0.65 | No Description |
Mills Hook Coupler
The Hook and base plate is made up of mild steel. Alternative to RAC
| Size | Weight | Item Description | Quantity | ||
|---|---|---|---|---|---|
| 48.3mm | 0.6 | No Description | |||
| default variation | 0.6 | No Description |
